Technology
Technical Overview
Frameset
Frame:
Roadmachine Carbon with Tuned Compliance Concept Endurance | Fender Mounts | Integrated Downtube Storage | Stealth Dropout Design | 12 x 142mm Thru-Axle
Fork:
Roadmachine Carbon with Tuned Compliance Concept Endurance | Fender Mounts | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Stem:
BMC RSM 01
Handlebar:
BMC RAB 03 | Ergo Top Shape | Compact Bend
Seat
Seatpost:
Roadmachine Carbon D-Shaped Seatpost | 15mm Offset | D-Fender Compatible
Saddle:
Fizik Taiga or Selle Royal SRX
Drivetrain
Crankset:
SHIMANO 105 (FC-R7100)
Chainrings:
50-34T
Cassette:
SHIMANO 105 (CS-R7101)
Cassette Size:
11-34T
Chain:
SHIMANO CN-M6100
Front Derailleur:
SHIMANO 105 (FD-R7100)
Rear Derailleur:
SHIMANO 105 (RD-R7100)
Shifters:
SHIMANO 105 (ST-R7120)
Gears:
2 x 12
Bottom Bracket:
PF86 Bottom Bracket
Brakes
Brake Levers / Calipers:
SHIMANO 105 (BR-R7170)
Rotors:
SHIMANO SM-RT70
Rotor Size (F/R):
160 / 160mm
Wheels
Rims:
Mavic Open Disc
Hubs (F/R):
CL-712 (F) | RXC-1425 (R) | Thru-Axle
Tires:
Vittoria Rubino IV G2.0 | Tube only | 30mm
Tubeless Information:
Tubetype Rims | Tubetype Tires
Accessories
In the Box:
Additional Information
Tire Clearance:
up to "40mm measured" (frameset clearance) but limited to "34mm measured" by the front derailleur
Weight without Pedals:
8.8 kg
ASTM Classification:
Level 2
System Weight Limit:
110kg
