Panoramica tecnica
Telaio
Telaio:
Speedfox 02 - Advanced Pivot System - Trailsync | 02 Carbon (F) - Al-13 Triple-butted aluminum (R)
Forcella:
02 Carbon (F) | Al-13 Triple-butted aluminum (R)
Cockpit
Piega:
BMC MRB 02 | 760mm
Attacco Manubrio:
BMC AMSM 02
Reggisella:
BMC Trailsync | 120mm*
Sella:
WTB Volt Race
Gruppo
Ingranaggi:
1 x 11
Guarnitura:
RaceFace Turbine Cinch 32T
Cassetta:
Shimano XT | 11-46T
Catena:
KMC X-11EL-1
Deragliatore Posteriore:
Shimano XT | Shadow Plus
Comandi:
Shimano XT
Freni
Leve Freno / Pinze:
Shimano XT (180/180mm)
Ruote
Cerchi:
DT Swiss M700 Spline 30**
Mozzi:
DT Swiss M1700 Spline
Pneumatici:
Ma x x is Forekaster E x O | 27,5 or 29 x 2.35
| Size | M | L | XL |
|---|---|---|---|
| Rider Height | |||
| Reach | 430 | 450 | |
| Stack | 610 | 620 | |
| Bar Drop | |||
| Bar Reach | |||
| Bar Rise | 15 | 15 | |
| Bar Sweep | 9 | 9 | |
| Bar Width | 760 | 760 | |
| Base Bar Drop Flat Cockpit | |||
| Base Bar Drop V-Cockpit | |||
| Base Bar Reach Flat Cockpit | |||
| Base Bar Reach V-Cockpit | |||
| BB Drop | 37 | 37 | |
| BB Drop (SLACK) | |||
| BB Drop (STEEP) | |||
| BB Height (SLACK) | |||
| BB Height (STEEP) | |||
| Chainstay | |||
| Crank Length | 175 | 175 | |
| LT | BB Drop (SLACK) | |||
| LT | BB Drop (STEEP) | |||
| LT | BB Height (SLACK) | |||
| LT | BB Height (STEEP) | |||
| LT | Chainstay | |||
| LT | Fork Length | |||
| LT | Fork Rake | |||
| LT | Frame Size | |||
| LT | Front Center (SLACK) | |||
| LT | Front Center (STEEP) | |||
| LT | Head Tube | |||
| LT | HT Angle (SLACK) | |||
| LT | HT Angle (STEEP) | |||
| LT | Reach (SLACK) | |||
| LT | Reach (STEEP) | |||
| LT | Rider Height | |||
| LT | Seat Tube | |||
| LT | ST Angle @750mm Saddle Height (SLACK) | |||
| LT | ST Angle @750mm Saddle Height (STEEP) | |||
| LT | ST Angle Actual (SLACK) | |||
| LT | ST Angle Actual (STEEP) | |||
| LT | ST Angle Effective (SLACK) | |||
| LT | ST Angle Effective (STEEP) | |||
| LT | Stack (SLACK) | |||
| LT | Stack (STEEP) | |||
| LT | Stand Over Height (80 in Front of BB) | |||
| LT | Stand Over Height (Lowest Point) | |||
| LT | Top Tube (SLACK) | |||
| LT | Top Tube (STEEP) | |||
| LT | Wheelbase (SLACK) | |||
| LT | Wheelbase (STEEP) | |||
| ST | BB Drop (SLACK) | |||
| ST | BB Drop (STEEP) | |||
| ST | BB Height (STACK) | |||
| ST | BB Height (STEEP) | |||
| ST | Chainstay | |||
| ST | Fork Length | |||
| ST | Fork Rake | |||
| ST | Frame Size | |||
| ST | Front Center (SLACK) | |||
| ST | Front Center (STEEP) | |||
| ST | Head Tube | |||
| ST | HT Angle (SLACK) | |||
| ST | HT Angle (STEEP) | |||
| ST | Reach (SLACK) | |||
| ST | Reach (STEEP) | |||
| ST | Rider Height | |||
| ST | Seat Tube | |||
| ST | ST Angle @750mm Saddle Height (SLACK) | |||
| ST | ST Angle @750mm Saddle Height (STEEP) | |||
| ST | ST Angle Actual (SLACK) | |||
| ST | ST Angle Actual (STEEP) | |||
| ST | ST Angle Effective (SLACK) | |||
| ST | ST Angle Effective (STEEP) | |||
| ST | Stack (SLACK) | |||
| ST | Stack (STEEP) | |||
| ST | Stand Over Height (80 in Front of BB) | |||
| ST | Stand Over Height (Lowest Point) | |||
| ST | Top Tube (SLACK) | |||
| ST | Top Tube (STEEP) | |||
| ST | Wheelbase (SLACK) | |||
| ST | Wheelbase (STEEP) | |||
| Fork Length | 526 | 526 | |
| Fork Rake | 51 | 51 | |
| Frame Size | |||
| Front Center | 704 | 728 | |
| Front Center (SLACK) | |||
| Front Center (STEEP) | |||
| Head Tube | 105 | 115 | |
| Head Tube Angle | 68.25 | 68.25 | |
| HT Angle (SLACK) | |||
| HT Angle (STEEP) | |||
| Pad Reach Flat Cockpit | |||
| Pad Reach V-Cockpit | |||
| Pad Stack Flat Cockpit | |||
| Pad Stack V-Cockpit | |||
| Reach (SLACK) | |||
| Reach (STEEP) | |||
| Rear Center | 445 | 445 | |
| Saddle Height Range | |||
| Seat Angle | 73.25 | 73.25 | |
| Seat Tube | 440 | 480 | |
| Seatpost Drop | |||
| Seatpost Length | |||
| Seatpost Offset | |||
| ST Angle @750mm Saddle Height (SLACK) | |||
| ST Angle @750mm Saddle Height (STEEP) | |||
| ST Angle Actual (SLACK) | |||
| ST Angle Actual (STEEP) | |||
| ST Angle Effective (SLACK) | |||
| ST Angle Effective (STEEP) | |||
| Stack (SLACK) | |||
| Stack (STEEP) | |||
| Stand Over Height (80 in Front of BB) | |||
| Stand Over Height (Lowest Point) | |||
| Standover Height | |||
| Stem Angle | |||
| Stem Length | 55 | 55 | |
| Top Tube | 611 | 634 | |
| Top Tube (SLACK) | |||
| Top Tube (STEEP) | |||
| Trail | 98 | 98 | |
| Wheelbase | 1145 | 1169 | |
| Wheelbase (SLACK) | |||
| Wheelbase (STEEP) |
